Car Lift Points: How to Find Lift Points on a Car

Every vehicle has a set of car lift points - specific spots on the undercarriage designed to handle the full weight of the vehicle when it's raised off the ground. Miss them, and you're looking at bent rocker panels, cracked oil pans, or worse.

Whether you're working with a 2-post car lift or a floor jack and stands, knowing how to find lift points on a car is the first thing to get right before anything leaves the ground. The tricky part is, they’re not the same across every vehicle. Don’t worry, though. You’ll feel confident in identifying lift points soon!

What Are Car Lift Points?

These manufacturer-designated contact areas on the underside of your vehicle are the specific spots where lift arms, jack saddles, or adapter pads are meant to make contact. They’re structurally reinforced to bear the vehicle's weight without deforming, and they're positioned to evenly distribute load across the chassis.

What happens if you lift somewhere else? The damage depends on where the pads land:

• Rocker panels: Thin sheet metal that bends or crimps under load. Often requires full panel replacement
• Oil pan: Cast aluminum on most modern engines, cracks easily under concentrated pressure
• Floor pan: Designed for road noise and moisture protection, not vertical load. It deforms permanently if lifted from
• Brake and fuel lines: Routed along the undercarriage and easy to pinch or rupture with a misplaced pad
• Suspension components: Control arms, tie rods, and sway bar links aren't designed for jacking load and can bend under the weight

The repair bill from a bad lift usually costs more than the service you were trying to do in the first place. Matching the right points to your car lift weight capacity is what keeps the whole process safe from start to finish.

Common Car Lift Points

Car lift points vary by vehicle type, but most fall into a handful of categories. Here are the most common contact areas you'll encounter:

• Pinch welds: The seam where the floor pan meets the rocker panel. This is the primary lift point on most unibody vehicles (cars, crossovers, and modern SUVs). Look for the reinforced or notched sections along this seam.
• Frame rails: The frame itself is the lift point on body-on-frame vehicles (trucks, full-size SUVs, older cars). Position pads on the flat, reinforced sections of the rail - not on brackets, wiring, or fuel lines.
• Subframe mounting points: Some vehicles have front and rear subframes bolted to the body. The mounting locations are meant to carry load and can be secondary car lift points.
• Crossmembers: The lateral structural members connecting the frame rails. These can serve as supplemental lift pad locations on trucks if you need to access areas of the undercarriage that you’d otherwise be lifting from (or blocking with the lift’s arms).
• Front engine crossmember (K-member): The crossmember that supports the engine and transmission cradle doubles as a front center lift point on many vehicles - both unibody and body-on-frame platforms.
• Rear axle housing: The rear axle itself is a common rear lift point on solid-axle trucks and SUVs. Position the pad on the axle tube, not on the differential cover.

Key takeaway: The specific combination depends on your vehicle. A symmetric vs asymmetric lift configuration also affects which car lift points you target. Asymmetric setups shift the vehicle's center of gravity forward, which changes where the rear arms need to land.

How to Find Lift Points on a Car

Don't guess if you've never lifted a particular vehicle before. You ALWAYS refer to the vehicle’s manual. Here's a step-by-step guide on how to find lift points on a car.

Check the Owner's Manual

Most owner's manuals have a diagram showing the recommended jack and lift point locations for that specific vehicle. Don't have the physical copy? Search “[year] [make] [model] owner's manual PDF.” Most manufacturers host them online for free.

Some vehicles also have a sticker inside the driver's door jamb or on the trunk lid with a simplified diagram. The manual will tell you exactly how to find lift points on a car for your make and model without the guesswork. Some manufacturers also publish lift point information in their online service portals, particularly for newer models.

Look for Visual Indicators on the Frame

There will be visual cues marking the car lift points once you're underneath the vehicle:

• Arrows or triangles stamped into the pinch weld or body seam
• Notches cut into the pinch weld at regular intervals (usually two per side)
• Reinforcement tabs: small metal flanges welded to the undercarriage at load-bearing spots
• Smooth, flat sections of the pinch weld (vs folded or crimped areas that can collapse under pressure)

Look for the thickest, most reinforced area along the rocker panel seam if nothing is obviously marked. That's typically where the manufacturer meant for lift pads to contact.

Avoid lifting on any section of the pinch weld that shows folding, crimping, or rust-through. Those areas have lost structural integrity. We say once more - refer back to the manual when in doubt before putting any weight on it. The stakes are too high to guess.

Unibody vs Body-on-Frame Vehicles

The vehicle's construction type determines how to find lift points on a car as well:

• Unibody (most modern cars, crossovers, some SUVs): The body and frame are one integrated structure. Lift points are the pinch welds along the rocker panels and designated subframe mounting points. Lifting on flat body panels (even ones that look sturdy) will cause deformation. The pinch weld is the engineered contact point, and the difference between a reinforced section and a non-reinforced section might only be an inch or two.
• Body-on-frame (trucks, full-size SUVs, older vehicles): The frame is a separate steel ladder underneath the body. Lift on the frame rails directly, not on the body panels above them. The frame is designed for load; the body is not. You typically have more flexibility in pad placement on these vehicles since the entire rail is structural. Still, avoid brackets, crossmember joints, and any area with fuel or brake line routing.

Make it a habit to adjust your lift arm position and pad type each time you switch between unibody and body-on-frame vehicles regularly. The contact points are fundamentally different.

Knowing how to position a car on a 2-post lift ties directly into this. Centering the vehicle and aligning the arms correctly is the next step once you've identified the car lift points.

Tips on Raising and Lowering Vehicles Safely

Knowing how to find lift points on a car is step one. Getting the vehicle raised safely is step two. This is the easy part:

• Confirm the vehicle's weight against your lift's rated capacity before raising anything (never assume it's fine, just as with trying to identify car lift points).
• Position all four lift pads squarely on the designated car lift points before activating the lift. Angled or offset pads slip under load.
• Raise a few inches, pause, and visually confirm all four contact points are solid. Rock the vehicle gently. Lower it and reposition if anything shifts.
• Never work under a vehicle only supported by a jack. Use jack stands at minimum - or better yet, use a full car lift for garage setups where mechanical locks hold the vehicle in place.
• Weight distribution matters even more on a single-post car lift since the entire load cantilevers from one column. Double-check your pad placement.
• Lower slowly and evenly. Sudden drops stress the lift points, damage components, and create a safety hazard.
• Keep the area underneath clear of tools, parts, and people while the vehicle is in motion.

Can you store a car on a 2-post lift safely if you plan to leave a vehicle elevated for extended periods (for long-term projects or storage)? It depends, but typically the answer is no. You’ll want a 4-post lift for that. We’ve got you covered with the top brands and models no matter your garage’s needs!

Parting Thoughts on Car Lift Points

Getting car lift points right isn't complicated, but it's not something to skip. The manual gives you the map. The visual indicators confirm it. And understanding whether you're working with a unibody or body-on-frame vehicle tells you where to look in the first place.

My Garage Supplies stocks the best lifts from the most trusted brands the industry has to offer, always priced as low as possible and backed by hassle-free financing. Our team can help you pick the perfect lift for your shop if you’re ready to upgrade. Get in touch today!

More Car Lift Articles to Read

Challenger vs BendPak | Atlas vs Rotary Lift | BendPak vs Triumph

Frequently Asked Questions

What are lift points on a car?

Reinforced spots on the vehicle's undercarriage (pinch welds, frame rails, subframe mounts) where lift arms or jack pads are designed to make contact. They're the only areas engineered to support the vehicle's full weight during a lift.

Where can I find vehicle lift points?

The owner's manual is the most reliable source as most include a diagram. Look under the vehicle for arrows, notches, or reinforced sections stamped into the pinch weld or frame rail. Find the thickest section of the rocker panel seam if nothing is marked.

Do all vehicles have lift points on the frame?

Only body-on-frame vehicles (trucks, full-size SUVs) have frame-rail lift points. Unibody vehicles (most modern cars and crossovers) don't have a separate frame. Their lift points are on the pinch welds and designated subframe locations instead.
