Overview
-The EKKO EB13C-118 Electric Straddle Stacker combines the functionality of a forklift, reach truck, and walkie stacker, making it an ideal solution for diverse applications such as loading and unloading trucks, managing loading docks, stock rooms, manufacturing floors, and warehouses.
Built with high-quality steel and durable components, this stacker is designed to handle various terrains, impacts, and directional changes, ensuring reliable performance and peace of mind in demanding environments.
Key Features
-- Load Capacity: 2800 lbs
- Raised Height: 118"
- Adjustable Forks: 8.6-32.1"
- Adjustable Legs: 35.4-51.2"
- Fork Length: 45.3"
- Controller: Curtis Instrument Controller
- Motors: DC Drive Motor and 24V Lift Motor
- Battery: 24V/85Ah included
- Wheels: Polyurethane for durability
- Ergonomic Controls: Easy-to-use handle and controls
- Construction: High-quality steel with robotic welding
Specifications
-Model | EB13C-118 | |
Load Capacity | (lbs) | 2800 |
Max Lifting Height | (in) | 118" |
Load Center Distance | (in) | 24 |
Fork Length | (in) | 45.3 |
Single Fork Width | (in) | 4 |
Fork Adjustment Width | (in) | 8.6-32.1 |
Lowered Fork Height | (in) | 2.56 |
Adjustable Legs | (in) | 35.4-51.2 |
Turning Radius | (in) | 56.1 |
Overall Length | (in) | 73.4 |
Max Overall Width | (in) | 61 |
Extended Mast Height | (in) | 127.6 |
Lowered Mast Height | (in) | 75.2 |
Battery Voltage | (V/Ah) | 24V/85Ah |
Internal Charger | (V/A) | 24V/10A |
Lifting Motor | (kW) | 2.2 kW |
Driving Motor | 0.75 kW | |
Service Weight | (lbs) | 1345 |
