Description
-Get the most out of your pool heating investment!
- High performance titanium heat exchanger
- Microprocessor controlled defrost cycle allows operation down to mid to low 40s F
- Built-in drain pan for condensate management
- Impact resistant, rust and fade proof cabinet
- Quieter than conventional heat pumps
- NEW Smart Microprocessor Control
- Weather protected microprocessor control with water temperature setpoint dial (60-104 F), easy to use and compatible with most external controllers
- Flip-out, lockable control panel is protected against sun and weather and can be easily programmed to prevent others from tampering with settings
- Ability to connect to most external controllers
- Rated in accordance with AHRI standard 1160.
Now you can control your heat pump right through your smartphone. Adjust your temperature setting in the PoolSync app.
*Additional purchase of PoolSync WiFi Controller required
Specifications
-BTUs (water temp/ambient air/relative humidity) |
T55 |
80/80/80 | 52,000 |
80/80/63 | 50,000 |
80/50/63 | 33,000 |
Coefficient of Performance
(water temp/ambient air/relative humidity) |
|
80/80/80 | 6 |
80/80/63 | 5.8 |
80/50/63 | 4 |
Refrigerant | R410A |
Heat Exchanger | Tube in Tube |
Electrical | |
kW Input | 2.7 |
Voltage/Hz/Phase | 208-230/60/1 |
Minimum Circuit Ampacity | 22.6 |
Maximum Fuse Size | 30 |
* Over Temperature Alarm Kit available: part number STK0221 for single phase, STK0222 for three phase. Strongly recommended for all spa applications. | |
Water Flow | |
Minimum/Maximum (gpm) | 20/45 |
* A Heater Bypass Kit is required when flow rates exceed the maximum: part number STK0135. | |
Physical | |
Weight (lbs) | 196 |
Length x Width x Height (in) | 34" x 34"x 28" |
Shipping | |
Weight (lbs) | 236 |
Length x Width x Height (in) | 37" x 36"x 34" |
Rated in accordance with AHRI standard 1160 water temp/ambient air/relative humidity.
