Description
-Get the most out of your pool heating investment!
- High performance titanium heat exchanger
- Microprocessor controlled defrost cycle allows operation down to mid to low 40s F
- Built-in drain pan for condensate management
- Impact resistant, rust and fade proof cabinet
- Quieter than conventional heat pumps
- NEW Smart Microprocessor Control
- Weather protected microprocessor control with water temperature setpoint dial (60-104 F), easy to use and compatible with most external controllers
- Flip-out, lockable control panel is protected against sun and weather and can be easily programmed to prevent others from tampering with settings
- Ability to connect to most external controllers
Rated in accordance with AHRI standard 1160.
Now you can control your heat pump right through your smartphone. Adjust your temperature setting in the PoolSync app.
*Additional purchase of PoolSync WiFi Controller required
Specifications
-BTUs (water temp/ambient air/relative humidity) |
T75 |
80/80/80 | 74,000 |
80/80/63 | 70,000 |
80/50/63 | 49,000 |
Coefficient of Performance
(water temp/ambient air/relative humidity) |
|
80/80/80 | 5.6 |
80/80/63 | 5.4 |
80/50/63 | 4 |
Refrigerant | R410A |
Heat Exchanger | Tube in Tube |
Electrical | |
kW Input | 3.9 |
Voltage/Hz/Phase | 208-230/60/1 |
Minimum Circuit Ampacity | 31.4 |
Maximum Fuse Size | 50 |
*Over Temperature Alarm Kit available: part number STK0221 for single phase, STK0222 for three phase. Strongly recommended for all spa applications. | |
Water Flow | |
Minimum/Maximum (gpm) | 20/45 |
*A Heater Bypass Kit is required when flow rates exceed the maximum: part number STK0135. | |
Physical | |
Weight (lbs) | 208 |
Length x Width x Height (in) | 34" x 34" x 28" |
Shipping | |
Weight (lbs) | 248 |
Length x Width x Height (in) | 37" x 36" x 34" |
Rated in accordance with AHRI standard 1160 water temp/ambient air/relative humidity
